10.57 G
10.57 gallons Spray Tank
Radar System
Phased Array Radar System
Vision
Binocular Vision System
Wind
Wind Resistance
Motors
Propulsion System - Motors
Smart Agricultrure
Smart Agriculture Cloud Platform
![Agras T50 drone Lightweight and Convenient](/img/backgrounds/midwest-air-drone-dji-t50-ready-to-fly.jpg)
Revolutionize Your Farming
Discover the Four-Nozzle Design of Agras T50 Drone.
- High output rate of up to .64 gallons per minute
- No Leakage
- Precise Volume control
Dual Atomizing Centrifugal Sprinklers
Adjustable Droplets
The DJI AGRAS T50 is equipped with dual atomizing centrifugal sprinklers, allowing for adjustable droplet sizes ranging from 50 to 500 μm, depending on the chemicals used. This advanced feature offers exceptional flexibility and precision in agricultural spraying, enabling operators to tailor droplet sizes to specific application requirements.
Proven for Reliability, Durability, and Safety
Fully Tested
Spraying and spreading operations are frequent, intense, and often occur in complex environments. The DJI AGRAS T50 has undergone hundreds of reliability tests to ensure it can withstand these challenging conditions. Its durable main body contributes to safe and consistent operation, providing peace of mind for users engaged in demanding agricultural tasks.
Orchard Aerial Survey
Better Coverage
The DJI AGRAS T50 is designed to support obstacle bypassing and Terrain Following for surveying orchards on slopes up to 20°. Using the DJI RC Plus and its real-time mapping capabilities, the T50 can automatically identify fruit trees and obstacles. This allows it to generate precise and fully automatic 3D flight routes based on the distribution of the fruit trees, enhancing the efficiency and accuracy of orchard surveys.
Spreading System
Smooth Spreading
The DJI AGRAS T50's Spreading System boasts an impressive capacity of 1,500 kg per hour. Equipped with a new spreader and a spiral channel spinning disk, this system significantly enhances spreading efficiency and smoothness. This advanced design ensures even and consistent distribution, optimizing application rates and coverage for various granular materials, making the T50 a powerful tool for modern agricultural operations.
DJI Relay (Optional)
Smooth Operation
The DJI AGRAS T50 offers an optional DJI Relay, which ensures smooth real-time video transmission even in complex operation scenarios with signal obstructions. This feature enhances flight safety by maintaining reliable communication and providing continuous video feed, allowing operators to navigate and monitor the drone with confidence, even in challenging environments. By maintaining a stable connection, the DJI Relay provides an added layer of security, ensuring that the T50 can perform optimally in diverse and demanding agricultural settings.
T50 Packages
Everything you need to be airborne today!
- 1 Full Set Propellers
- 1 Motor
- 1 Tank Lid
- 1 ESC
DJI AGRAS T50 Specifications
Aircraft Specs
Weight | 87.96 lbs (excl. battery) 114.64 lbs (incl. battery) |
---|---|
Max Takeoff Weight | Max takeoff weight for spraying: 202.82 lbs (at sea level) Max takeoff weight for spreading: 227.08 lbs (at sea level) |
Max Diagonal Wheelbase | 86.61 inches |
Dimensions | 110.24×121.46×32.28 inches (arms and propellers unfolded) 62.6×74.8×32.28 inches (arms unfolded and propellers folded) 43.9×29.53×35.43 inches (arms and propellers folded) |
Hovering Accuracy Range (with strong GNSS signal) | D-RTK enabled: Horizontal: ±3.94 inches, Vertical: ±3.94 inches D-RTK disabled: Horizontal: ±23.62 inches, Vertical: ±11.81 inches (radar module enabled: ±3.94 inches) |
RTK/GNSS Operating Frequency | RTK: GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galileo E1/E5b, QZSS L1/L2 GNSS: GPS L1, GLONASS F1, BeiDou B1I, Galileo E1, QZSS L1 |
Max Configurable Flight Radius | 6561.68 feet |
Max Wind Resistance | 13.42 mph |
Binocular Vision System
Measurement Range | 1.64-95.14 ft |
---|---|
Effective Sensing Speed | ≤22.37 mph |
FOV | Horizontal: 90°, Vertical: 106° |
Operating Environment | Adequate light and discernible surroundings |
Dual Atomizing Spraying System - Spray Tank
Material | Plastic (HDPE) |
---|---|
Volume | 10.57 gallons |
Operating Payload | 88.18 lbs |
Quantity | 1 |
Dual Atomizing Spraying System - Sprinklers
Model | LX8060SZ |
---|---|
Quantity | 2 |
Nozzle Distance | 61.81 inches (Rear Nozzles) |
Droplet Size | 50-500 μm |
Effective Spray Width | 13.12-36.09 feet (at a height of 9.84 feet above the crops) |
Dual Atomizing Spraying System - Delivery Pumps
Type | Impeller pump (magnetic drive) |
---|---|
Quantity | 2 |
Single Pump Flow Rate | 0-3.17 gal/min |
Max Flow Rate | 4.23 gal/min (2 nozzles); 6.34 gal/min (4 nozzles) |
Battery Specs
Model | DB1560 Intelligent Flight Battery (BAX702-30000mAh-52.22V) |
---|---|
Weight | Approx. 26.68 lbs |
Capacity | 30000 mAh |
Nominal Voltage | 52.22 V |
